P–104
TROUBLESHOOTING (ABS/TCS/DYNAMIC STABILITY CONTROL)
SYMPTOM TROUBLESHOOTING
A6E699067650W04
• Verify the symptoms, and perform troubleshooting according to the appropriate number.
Vehicles with ABS/TCS
Vehicles with DSC
*1
: DSC system contains traction control function, DSC indicator light goes on and off while DSC operates.
*2
: DSC indicator light goes on and off while DSC operates.
No. Symptom
1 ABS warning light, BRAKE system warning light, TCS OFF light do not illuminate with ignition switch on.
2 Neither ABS warning light nor BRAKE system warning light illuminate with ignition switch on.
3 ABS warning light does not illuminate with ignition switch on.
4 BRAKE system warning light does not illuminate with ginning switch on.
5 TCS OFF light and TCS indicator light do not illuminate with ignition switch on.
6 Both ABS warning light and BRAKE system warning light stay on more than 4 seconds with ignition with on.
7 ABS warning light stays on more than 4 seconds with ingestion switch on.
8 BRAKE system warning light stays on more than 4 seconds with ignition switch on. (Parking brake is released.)
9 TCS OFF light stays on more than 4 seconds with ignition switch on.
10 TCS does not work correctly.
11 There is a malfunction in the system even through ABS warning light, BRAKE system warning light, TCS OFF
light,TCS indicator light do not illuminate.
No. Symptom
1 Any of the following lights do not illuminate with ignition switch on.
• ABS warning light
• BRAKE system warning light
• DSC indicator light
• DSC OFF light
2 Any of the following lights stay on:
• ABS warning light.
• BRAKE system warning light
• DSC indicator light
• DSC OFF light
3 There is a malfunction in the system even though ABS warning light, BRAKE system warning light, DSC indicator light
and DSC OFF light do not illuminate.
4
ABS or TCS
*1
operates frequently.
TCS does not work correctly.
5
DSC
*2
operates frequently.
DSC does not work correctly.
6 DSC indicator light flashes (when neither the TCS nor the DSC are operating).
To Next Page
