ON-BOARD DIAGNOSTIC [AIR BAG SYSTEM]
T–197
T
End Of Sie
ACTIVE COMMAND MODE TABLE
A6E817401046W04
End Of Sie
OD_P_PSAB_ST
(On demand passenger-side
side air bag sensor circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2I, 2L
P_ABAGR2
(Passenger-side air bag
module (inflator No.2)
resistance)
ohm Under any condition: 1.4—2.9 ohm 1A, 1D
P_PTENSFLT
(Passenger-side pre-tensioner
seat belt circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2G, 2J
PABAGR
(Passenger-side air bag
module (inflator No.1)
resistance)
ohm Under any condition: 1.4—2.9 ohm 1M, 1P
PCRSH_SNSR
(Passenger-side side air bag
sensor state)
OK/
COMM FAIL/
INT FAIL
• Sensor normal: OK
• Sensor communication error: COMM FAIL
• Sensor internal circuit abnormal: INT FAIL
2B, 2C
PS_AB
(Passenger-side side air bag
module resistance)
ohm Under any condition: 1.4—3.2 ohm 2I, 2L
PS_AB_ST
(Passenger-side side air bag
sensor circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2I, 2L
PS_CURTN
(Passenger-side curtain air
bag module resistance)
ohm Under any condition: 1.4—3.2 ohm 2A, 2B
PS_CURT_ST
(Passenger-side curtain air
bag module circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2A, 2D
PS_PTENS
(Passenger-side pre-tensioner
seat belt resistance)
ohm Under any condition: 1.5—3.1 ohm 2G, 2J
PS1_STAT
(Passenger-side air bag
module (inflator No.1) circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1M, 1P
PS2_STAT
(Passenger-side air bag
module (inflator No.2) circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1A, 1D
PSB_P_ST
(On demand passenger-side
pre-tensioner seat belt circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2G, 2J
RCM_VOLT
(System IG1 voltage value)
V
• Ignition switch to ON position: B+
• Other: 0 V
1W
PID name (definition) Unit/condition Condition/specification
SAS unit
terminal
Command name Definition Operation
WRNLAMPCHM Air bag system warning light ON/OFF
