T–196
ON-BOARD DIAGNOSTIC [AIR BAG SYSTEM]
DS_AB_ST
(Driver-side side air bag
module circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2M, 2O
DS_CURT_ST
(Driver-side curtain air bag
module circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2V, 2Y
DS1_STAT
(Driver-side air bag module
(inflator No.1) circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1S, 1V
DS2_STAT
(Driver-side air bag module
(inflator No.2) circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1G, 1J
DSB_P_ST
(On demand driver-side pre-
tensioner seat belt circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2P, 2S
DSSBLT_PF
(Driver-side pre-tensioner seat
belt circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2P, 2S
FRNT_CRSH_SNSR
(Crash zone sensor state)
OK/
COMM FAIL/
INT FAIL
• Sensor normal: OK
• Sensor communication error: COMM FAIL
• Sensor internal circuit abnormal: INT FAIL
1B, 1C
OD_D_CRSH
(On demand driver-side side
air bag sensor state)
OK/
COMM FAIL/
INT FAIL
• Sensor normal: OK
• Sensor communication error: COMM FAIL
• Sensor internal circuit abnormal: INT FAIL
2Z, 2AA
OD_D_CURT
(On demand driver-side
curtain air bag module circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2V, 2Y
OD_DAB1_ST
(On demand driver-side air
bag module (inflator No.1)
circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1S, 1V
OD_DAB2_ST
(On demand driver-side air
bag module (inflator No.2)
circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1G, 1J
OD_DSAB_ST
(On demand driver-side side
air bag circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2M, 2O
OD_F_CRSH
(On demand crash zone
sensor state)
OK/
COMM FAIL/
INT FAIL
• Sensor normal: OK
• Sensor communication error: COMM FAIL
• Sensor internal circuit abnormal: INT FAIL
1B, 1C
OD_P_CRSH
(On demand passenger-side
side air bag sensor state)
OK/
COMM FAIL/
INT FAIL
• Sensor normal: OK
• Sensor communication error: COMM FAIL
• Sensor internal circuit abnormal: INT FAIL
2B, 2C
OD_P_CURT
(On demand passenger-side
curtain air bag module circuit
state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
2A, 2D
OD_PAB1ST
(On demand passenger-side
air bag module (inflator No.1)
circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1M, 1P
OD_PAB2_ST
(On demand passenger-side
air bag module (inflator No.2)
circuit state)
NORMAL/
OPEN/
SHRT GND/
SHRT B+
• Related wiring harness normal: NORMAL
• Related wiring harness circuit open: OPEN
• Related wiring harness short to ground: SHRT GND
• Related wiring harness short to power supply: SHRT B+
1A,1D
PID name (definition) Unit/condition Condition/specification
SAS unit
terminal
