S–74
SLIDING SUNROOF
DEFLECTOR REMOVAL/INSTALLATION
A6E774069880W01
1. Fully open the glass panel.
2. Remove the headliner.
3. Remove the screws.
4. Disengage the hooks.
(1) Press the rear end of each hook.
(2) After sliding the hooks rearward, press them upward.
5. Remove the deflector.
6. Install in the reverse order of removal.
End Of Sie
GLASS PANEL REMOVAL/INSTALLATION
A6E774069810W01
1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, and then remove the glass
panel.
4. Peel the weatherstrip off the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See S–75 GLASS PANEL
ADJUSTMENT.)
SLIDING SUNROOF
A6E7740W003
A6E7740W004
A6E7740W006
