E–6
RADIATOR
End Of Sie
RADIATOR REMOVAL/INSTALLATION
A6E361615200W01
1. Disconnect the negative battery cable.
2. Drain the engine coolant. (See E–4 ENGINE COOLANT REPLACEMENT.)
3. Remove the cooling fan. (See E–9 COOLING FAN REMOVAL/INSTALLATION.)
4. Remove the oil hose. (ATX)
5. Remove in the order indicated in the table.
6. Install in the reverse order of removal.
7. Refill the engine coolant. (See E–4 ENGINE COOLANT REPLACEMENT.)
8. Inspect the engine coolant leakage. (See E–4 ENGINE COOLANT LEAKAGE INSPECTION.)
.
End Of Sie
RADIATOR
AME3616W001
1 Water hose 2Radiator
