T–238
TROUBLESHOOTING
End Of Sie
2 CONFIRM THAT MALFUNCTION SYMPTOMS
DO NOT RECUR AFTER REPAIR
• Connect all SAS unit connectors.
• Connect driver and passenger-side
pre-tensioner seat belt connectors. (Vehicles
with pre-tensioner seat belt)
• Connect driver and passenger-side curtain
air bag module connectors. (Vehicles with
curtain air bag)
• Connect driver and passenger-side side air
bag module connectors. (Vehicles with side
air bag)
• Connect passenger-side air bag module
connector.
• Connect clock spring connector.
• Connect negative battery cable.
• Turn ignition switch to ON position.
• Does passenger-side air bag cut-off indicator
light operate properly?
Yes Complete troubleshooting, then explain repairs to customer.
No Recheck malfunction symptoms, then repeat from Step 1 if
malfunction recurs.
STEP INSPECTION ACTION
To Next Page
