LOCATION INDEX
U–3
U
BASIC SYSTEM
A6E850001040W01
.
LOCATION INDEX
A6E8500W001
A6E8500W002
1 Blower unit
(See U–14 BLOWER UNIT REMOVAL/
INSTALLATION)
(SeeU–14 BLOWER UNIT DISASSEMBLY/
ASSEMBLY)
2 Air filter
(See U–15 AIR FILTER REMOVAL/INSTALLATION)
(See U–15 AIR FILTER INSPECTION)
3A/C unit
(See U–15 A/C UNIT REMOVAL/INSTALLATION)
(See U–18 A/C UNIT DISASSEMBLY/ASSEMBLY)
4 Rear heat duct
(See U–23 REAR HEAT DUCT REMOVAL/
INSTALLATION)
5A/C compressor
(See U–23 A/C COMPRESSOR REMOVAL/
INSTALLATION)
6 Condenser
(See U–24 CONDENSER REMOVAL/
INSTALLATION)
(See U–24 CONDENSER INSPECTION)
7 Heater hose
8 Refrigerant lines
(See U–25 REFRIGERANT LINES REMOVAL/
INSTALLATION)
