CONTROL SYSTEM
U–31
U
End Of Sie
AIR MIX ACTUATOR REMOVAL/INSTALLATION
A6E854061415W01
1. Disconnect the negative battery cable.
2. Remove the glove compartment.
3. Remove the car navigation unit. (See T–98 CAR-NAVIGATION UNIT REMOVAL/INSTALLATION.)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
End Of Sie
A6E8540W043
1 Air mix actuator connector
2 Air mix actuator
A6E8540W004
To Next Page
