EXHAUST SYSTEM
F–37
F
HO2S Removal Note
1. Remove the HO2S using the SST before
removing the exhaust manifold.
Exhaust Manifold Installation Note
1. Tighten the exhaust manifold installation nuts in
the order shown.
End Of Sie
1 Main silencer
2 Middle pipe
3TWC
4 Exhaust manifold insulator (upper)
5Bracket
6 Exhaust manifold
(See F–37 Exhaust Manifold Installation Note)
7 Exhaust manifold gasket
8 Exhaust manifold insulator (lower)
9 HO2S (front)
(See F–37 HO2S Removal Note)
10 HO2S (rear)
(See F–37 HO2S Removal Note)
A6J3914W004
A6E3914W003
