Mazda 2002 6 - Page 159

F–44
CONTROL SYSTEM
European (L.H.D.) specs.
.
Set Nut/bolt Removal Note
1. Using a chisel and a hammer, cut a groove on the head of the set nut/bolt so that a screwdriver can be
inserted.
2. Loose the set nut/bolt using an impact
screwdriver or pliers.
Set Nut/bolt Installation Note
1. Install a new set nut/bolt and tighten it until the
neck of the nut/bolt is cut.
End Of Sie
A6E3940W001
1 PCM cover
2 PCM connector
3PCM
A6E3940W003
A6E3940W004
