F–180
ON-BOARD DIAGNOSTIC
End Of Sie
6 INSPECT GENERATOR CONTROL TERMINAL
FOR SHORT TO POWER
• Measure resistance between generator
terminal D (part-side) and body ground.
• Is voltage B+?
Yes Repair or replace generator, then go to Step 7.
No Go to next step.
7 VERIFY TROUBLESHOOTING OF DTC P2504
COMPLETED
• Make sure to reconnect all connectors.
• Clear DTC from PCM memory using WDS or
equivalent.
• Perform KOER self-test.
(See F–66 KOEO/KOER SELF-TEST.)
• Is same DTC present?
Yes Replace PCM, then go to next step.
(See F–43 PCM REMOVAL/INSTALLATION.)
No Go to next step.
8 VERIFY AFTER REPAIR PROCEDURE
• Perform “After Repair Procedure”.
(See F–66 AFTER REPAIR PROCEDURE.)
• Is there any DTC present?
Yes Go to applicable DTC troubleshooting.
(See F–67 DTC TABLE.)
No Troubleshooting completed.
STEP INSPECTION ACTION
