K–32
AUTOMATIC TRANSAXLE
4. Remove the transaxle.
Transaxle Installation Note
1. Set the transaxle on a jack and lift it.
2. Install the transaxle mounting bolts.
Tightening torque
37.3—52 N·m {3.8—5.3 kgf·m, 28—38 ft·lbf}
Torque Converter Nuts Removal Note
1. Hold the cankshaft pulley to prevent drive plate
from rotating.
2. Remove the torque converter nuts from the
starter installation hole.
A6E5614W051
A6E5614W052
A6E5614W091
A6E5614W092
