AUTOMATIC TRANSAXLE SHIFT MECHANISM
K–50–1
K
K–50
AUTOMATIC TRANSAXLE
SELECTOR LEVER REMOVAL/INSTALLA TION
A6E56164 6102W03B
Interlock Cable Installation Note
15. Connect the brake switch connector with the brake pedal released.
Caution
• The clearance between the brake switch and the brake pedal is automatically adjusted to the
correct amount when the brake switch connector is connected after the brake switch has been
properly installed. If the brake switch is not properly installed or the connector is connected
before installation, the clearance may be incorrect, causing a brake light malfunction. Therefore,
always verify that the brake switch is properly installed before connecting the connector.
• Once the brake switch clearance has automatically been adjusted, it cannot be adjusted again.
Therefore, replace the switch with a new one when replacing the power brake unit or the pedal, or
performing any procedure that changes the pedal stroke.
16. Turn the ignition switch to ON position.
17. Install the interlock cable to the key cylinder.
18. Slide the outer casing to the key cylinder, and
insert the clip over the convex part of the outer
casing.
End Of Sie
AUTOMATIC TRANSAXLE SHIFT MECHANISM
A6E5616W014
