Mazda 2002 6 - Page 569

DRIVE SHAFT
M–27
M
Standard length
mm {in}
6. Release any trapped air from the boots by
carefully lifting up the small end of each boot with
a cloth wrapped screwdriver.
Caution
• Be careful not to allow the grease to leak.
• Do not damage the boot.
7. Verify that the drive shaft length is within the
specification.
End Of Sie
Left side Right side
L8, LF
677.7—687.7
{26.69—27.07}
628.6—638.6
{24.75—25.14}
L3
676.6—686.6
{26.64—27.03}
A6E6316W007
