ON-BOARD DIAGNOSTIC (DYNAMIC STABILITY CONTROL)
ABS_LAMP
(ABS warning light driver
output state)
ON/OFF
• ABS warning light is
illuminated: ON
• ABS warning light is not
illuminated: OFF
Inspect ABS warning light.
—
BRAKE_LMP
(BRAKE system warning
light output state)
ON/OFF
• BRAKE system warning
light is illuminated: ON
• BRAKE system warning
light is not illuminated:
OFF
Inspect BRAKE system
warning light.
—
ABSRR_O
(Right rear ABS pressure
reduction solenoid valve
output state)
ON/OFF
• During ABS control: ON/
OFF (solenoid valve is
activated/deactivated)
• Not ABS control: OFF
• (solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION)
—
ABSLR_O
(Left rear ABS pressure
reduction solenoid valve
output state)
ON/OFF
• During ABS or EBD
control: ON/OFF
(solenoid valve is
activated/deactivated)
• Not ABS and EBD control:
OFF (solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION) —
ABSRF_O
(Right front ABS pressure
reduction solenoid valve
output state)
ON/OFF
• During ABS control: ON/
OFF (solenoid valve is
activated/deactivated)
• Not ABS control: OFF
(solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION)
—
ABSLF_O
(Left front ABS pressure
reduction solenoid valve
output state)
ON/OFF
• During ABS control: ON/
OFF(solenoid valve is
activated/deactivated)
• Not ABS control: OFF
(solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION)
—
ABSRR_I
(Right rear ABS pressure
reduction solenoid valve
output state)
ON/OFF
• During ABS control: ON/
OFF (solenoid valve is
activated/deactivated)
• Not ABS control: OFF
(solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION)
—
ABSLR_I
(Left rear ABS pressure
retention solenoid valve
output state)
ON/OFF
• During ABS or EBD
control: ON/OFF
(solenoid valve is
activated/deactivated)
• Not ABS and EBD control:
OFF (solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION) —
ABSRF_I
(Right front ABS pressure
retention solenoid valve
output state)
ON/OFF
• During ABS control: ON/
OFF (solenoid valve is
activated/deactivated)
• Not ABS control: OFF
(solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION)
—
ABSLF_I
(Left front ABS pressure
retention solenoid valve
output state)
ON/OFF
• During ABS control: ON/
OFF (solenoid valve is
activated/deactivated)
• Not ABS control: OFF
(solenoid valve is
deactivated)
Internal fault of DSC HU/
CM. Replace DSC HU/CM.
(See P–38 DSC HU/CM
REMOVAL/INSTALLATION)
—
ABSVLVRLY
(Fail-safe relay output
state)
ON/OFF
• Fail-safe relay is
activated: ON
• Fail-safe relay is
deactivated: OFF
Inspect DSC HU/CM.
(See P–40 DSC HU/CM
INSPECTION )
—
PID Name
(Definition)
Unit/Condition Condition/Specification Action
ABS/TCS HU/
CM or DSC HU/
CM terminal
