R–24
FRONT SUSPENSION
.
A6E7414W100
1 Nut (stabilizer control link)
2 Front lower arm (front) ball joint
(See R–16 Front Lower Arm (Front) Ball Joint
Removal Note)
3 Front lower arm (rear) ball joint
(See R–19 Front Lower Arm (Rear) Ball Joint
Removal Note)
4 Bolt (front shock absorber lower side)
5 No.1 engine mount center bolt
(See R–25 No.1 Engine Mount Center Bolt Removal
Note)
6 Crossmember bracket
(See R–25 Crossmember Bracket Removal Note)
7 Crossmember component
8 Stabilizer bracket and bushing
9 Front Stabilizer
10 Front lower arm (front)
11 Front lower arm (rear)
12 Front crossmember
13 Front crossmember bushing
(See R–25 Front Crossmember Bushing Removal
Note)
(See R–26 Front Crossmember Bushing Installation
Note)
