R–36
REAR SUSPENSION
.
A6E7416W018
1 ABS wheel-speed sensor
2 Parking brake cable
3 Calliper component
(See R–37 Caliper Component Removal Note)
4Disc plate
5 Spindle and hub component
(See M–10 WHEEL HUB, HUB SPINDLE
REMOVAL/INSTALLATION)
6 Bolt (stabilizer control link lower side)
7 Bolt (rear lower arm outer side)
(See R–29 Bolt (Rear Lower Arm Outer Side)
Removal Note)
8 Spring component
9 Bolt (rear shock absorber lower side)
10 Bolt (trailing link front side)
(See R–37 Bolt (Trailing Link Front Side) Removal
Note)
(See R–37 Bolt (Trailing Link Front Side) Installation
Note)
11 Bolt (rear lateral link outer side)
(See R–37 Bolt (Rear Lateral Link Outer Side)
Removal Note)
12 Bolt (rear upper arm outer side)
13 Trailing link
