WIPER AND WASHER
T–67
T
End Of Sie
WIPER AND WASHER SWITCH REMOVAL/INSTALLATION
A6E811666122W01
1. Disconnect the negative battery cable.
2. Remove the column cover. (See S–84 COLUMN COVER REMOVAL/INSTALLATION)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
G
Rear wiper
switch INT
Rear wiper switch
Ignition switch at
ON position
Rear wiper
switch at INT
position
0
• Inspect R. WIP 10 A
fuse
• Inspect wiper and
washer switch (See T–
68 WIPER AND
WASHER SWITCH
INSPECTION)
• Inspect related harness
• Rear wiper
switch at
OFF position
• Rear wiper
switch at ON
position
B+
I IG 2 R. WIP 10 A fuse
Ignition switch at ON position B+ • Inspect R. WIP 10 A
fuse
• Inspect related harness
Other 0
Terminal Signal Connected to Test condition
Voltage (V)/
Continuity
Action
1 Connector
2Screw
3 Wiper and washer switch
A6E8116W203
A6E8116W204
