17.2 Remote STOP
J(P).RSTOP, G(P).RSTOP, Z(P).RSTOP
These instructions execute remote STOP for the programmable controller on another station.
■Execution condition
Ladder ST
ENO:=J_RSTOP(EN,J,s1,s2,s3,s4,d);
ENO:=JP_RSTOP(EN,J,s1,s2,s3,s4,d);
ENO:=G_RSTOP(EN,U,s1,s2,s3,s4,d);
ENO:=GP_RSTOP(EN,U,s1,s2,s3,s4,d);
ENO:=Z_RSTOP(EN,J/U,s1,s2,s3,s4,d);
ENO:=ZP_RSTOP(EN,J/U,s1,s2,s3,s4,d);
FBD/LD
Instruction Execution condition
J.RSTOP
G.RSTOP
Z.RSTOP
JP.RSTOP
GP.RSTOP
ZP.RSTOP
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(J/U) (s1) (s2) (s3) (s4) (d)
EN ENO
J/U
s1
d
s2
s3
s4
