25 TYPE CONVERSION FUNCTIONS
25.68 Copying the Specified Bit of the Word Label
25.68 Copying the Specified Bit of the Word Label
CPY_BIT_OF_INT(_E)
These functions copy the specified bit of the word label to the specified bit of another word label.
*1 FBD/LD is not supported. For FBD/LD, use the bit specification of labels.
Setting data
■Description, type, data type
Processing details
■Operation processing
• These functions copy the value in the (n1)th bit of the word specified by (s) to the (n2)th bit of (d).
■Operation result
1. Function without EN/ENO
The operation processing is performed. The operation result is output from (d).
2. Function with EN/ENO
The execution conditions and operation results will be as follows.
*1 If the value FALSE is output from ENO, the output data from (d) will be undefined. Create a program so that the undefined value will not
be used in operations.
Ladder
*1
Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=CPY_BIT_OF_INT(s,n1,n2);
[With EN/ENO]
d:=CPY_BIT_OF_INT_E(EN,ENO,s,n1,n2);
Argument Description Type Data type
EN Execution condition (TRUE: Executed, FALSE: Not executed) Input variable BOOL
s Input Input variable INT
n1 Number of bits in input variable (0 to 15) Input variable INT
n2 Number of bits in output variable (0 to 15) Input variable INT
ENO Output status (TRUE: Normal, FALSE: Abnormal or operation stop) Output variable BOOL
d Input/output Input/output variable INT
Execution condition Operation result
EN ENO (d)
TRUE (executed) TRUE Operation result output value
FALSE (not executed) FALSE
*1
Undefined value
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
sd
n1
n2
EN ENO
ds
n1
n2
