7 APPLICATION INSTRUCTIONS
7.20 Data Processing Instructions
Searching the minimum value of 16-bit binary data
MIN(P)(_U)
These instructions search the (n) points of 16-bit binary data in the specified device for the minimum value.
*1 The MIN and MIN_U instructions do not support the ST and FBD/LD. Use the standard function, MIN.
Page 1933 MAX(_E), MIN(_E)
■Execution condition
Setting data
■Description, range, data type
*1 When specifying setting data by using a label, define an array to secure enough operation area and specify an element of the array
label.
■Applicable devices
Ladder ST
*1
ENO:=MINP(EN,s,n,d); ENO:=MINP_U(EN,s,n,d);
FBD/LD
*1
Instruction Execution condition
MIN
MIN_U
MINP
MINP_U
Operand Description Range Data type Data type (label)
(s) MIN(P) Start device where the search target data is
stored
 16-bit signed binary ANY16_S
*1
MIN(P)_U 16-bit unsigned binary ANY16_U
*1
(d) MIN(P) Start device for storing the search result of the
minimum value
 16-bit signed binary ANY16_S_ARRAY
(Number of elements: 3)
MIN(P)_U 16-bit unsigned binary ANY16_U_ARRAY
(Number of elements: 3)
(n) Number of search data 0 to 65535 16-bit unsigned binary ANY16
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)         
(d)         
(n)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d) (n)
EN ENO
sd
n
