6 BASIC INSTRUCTIONS
6.7 Data Transfer Instructions
Inverting and transferring 16-bit binary data
CML(P)
These instructions invert the specified 16-bit binary data bit by bit, and transfer the inverted data.
■Execution condition
Setting data
■Description, range, data type
• In safety programs executed by the Safety CPU, only safety devices and safety labels of data types described in the table
can be used.
■Applicable devices
• In safety programs executed by the Safety CPU, only the following safety devices and constants can be used.
Ladder ST
ENO:=CML(EN,s,d);
ENO:=CMLP(EN,s,d);
FBD/LD
Instruction Execution condition
CML
CMLP
Operand Description Range Data type Data type (label)
(s) Inversion target data or the number of the device where the
inversion target data is stored
-32768 to 32767 16-bit signed binary ANY16
(d) Number of the device for storing the inverted data  16-bit signed binary ANY16
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)         
(d)         
Operand Bit Word Constant
SA\X, SA\Y, SA\M, SA\SM, SA\B SA\T, SA\ST, SA\C, SA\D, SA\W, SA\SD K, H
(s) 
(d) 
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d)
EN ENO
ds
