Mitsubishi Electric MELSEC iQ-R Series - Converting Binary Data to BCD 8-Digit Data

380
6 BASIC INSTRUCTIONS
6.6 Data Conversion Instructions
Converting binary data to BCD 8-digit data
DBCD(P)
These instructions convert the specified 32-bit binary data to BCD 8-digit data.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
ENO:=DBCD(EN,s,d);
ENO:=DBCDP(EN,s,d);
FBD/LD
Instruction Execution condition
DBCD
DBCDP
Operand Description Range Data type Data type (label)
(s) Binary data or the start device where the binary data is
stored
0 to 99999999 32-bit signed binary ANY32
(d) Start device for storing the converted BCD data  BCD 8-digit ANY32
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)         
(d)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d)
EN ENO
ds
