Mitsubishi Electric MELSEC iQ-R Series - Copying the Bit Array

25 TYPE CONVERSION FUNCTIONS
25.65 Copying the Bit Array
1885
25
25.65 Copying the Bit Array
CPY_BITARR(_E)
These functions copy the bit array by the specified number of bits.
Setting data
■Description, type, data type
Processing details
■Operation processing
• These functions output the bit array (number of (n) bits) specified by (s) to (d).
■Operation result
1. Function without EN/ENO
The operation processing is performed. The operation result is output from (d).
2. Function with EN/ENO
The execution conditions and operation results will be as follows.
*1 If the value FALSE is output from ENO, the output data from (d) will be undefined. Create a program so that the undefined value will not
be used in operations.
Operation error
There is no operation error.
Ladder, FBD/LD Structured text
[Without EN/ENO] [With EN/ENO] [Without EN/ENO]
d:=CPY_BITARR(s,n);
[With EN/ENO]
d:=CPY_BITARR_E(EN,ENO,s,n);
Argument Description Type Data type
EN Execution condition (TRUE: Executed, FALSE: Not executed) Input variable BOOL
s(BitArrIn) Input Input variable Boolean array element
n Number of bits (4, 8, 12, 16, 20, 24, 28, or 32) Input variable INT
ENO Output status (TRUE: Normal, FALSE: Abnormal or operation stop) Output variable BOOL
d Output Output variable Boolean array element
Execution condition Operation result
EN ENO (d)
TRUE (executed) TRUE Operation result output value
FALSE (not executed) FALSE
*1
Undefined value
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
s d
n
EN ENO
sd
n
