Mitsubishi Electric MELSEC iQ-R Series - Dead Time

11 PROCESS CONTROL INSTRUCTIONS
11.3 Control Operation Instructions
1295
11
Dead time
S.DED
This instruction outputs the input data with the delay by the specified dead time.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
ENO:=S_DED(EN,s1,s2,d1,d2);
FBD/LD
Instruction Execution condition
S.DED
Operand Description Range Data type
(s1) Input data start device Refer to "Input data". Word
(d1) Block memory start device Refer to "Block memory". Word
(s2) Operation constant start device Refer to "Operation constant". Word
(d2) Local work memory start device Refer to "Local work memory". Word
EN Execution condition  Bit
ENO Execution result  Bit
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, R, ZR,
RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s1)         
(d1)         
(s2)         
(d2)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s1) (d1) (s2) (d2)
EN ENO
d1
d2
s1
s2
