Mitsubishi Electric MELSEC iQ-R Series - Output Processing 1 with Mode Switching

11 PROCESS CONTROL INSTRUCTIONS
11.2 I/O Control Instructions
1203
11
Output processing 1 with mode switching
S.OUT1
This instruction calculates MV (0 to 100%) from input data (MV), performs variation rate & upper/lower limiter processing,
and output conversion.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
■Input data
Ladder ST
ENO:=S_OUT1(EN,s1,s2,d1,d2);
FBD/LD
Instruction Execution condition
S.OUT1
Operand Description Range Data type
(s1) Input data start device Refer to "Input data". Single-precision real
number
(d1) Block memory start device Refer to "Block memory". Word
(s2) Operation constant start device Refer to "Operation constant". Word
(d2) Loop tag memory start device Refer to "Loop tag memory". Word
EN Execution condition  Bit
ENO Execution result  Bit
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, R, ZR,
RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s1)         
(d1)         
(s2)         
(d2)         
Operand: (s1)
Position Symbol Name Recommended range Data type Standard
value
Set by
+0
+1
E1 Input value
(MV)
-999999 to 999999 [%] Single-precision
real number
 User
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s1) (d1) (s2) (d2)
EN ENO
d1
d2
s1
s2
