Mitsubishi Electric MELSEC iQ-R Series - Converting Single-Precision Real Number to BCD Format Data

6 BASIC INSTRUCTIONS
6.6 Data Conversion Instructions
465
6
Converting single-precision real number to BCD format data
EMOD(P)
These instructions convert single-precision real number data to the BCD floating point format data.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
ENO:=EMOD(EN,s1,s2,d);
ENO:=EMODP(EN,s1,s2,d);
FBD/LD
Instruction Execution condition
EMOD
EMODP
Operand Description Range Data type Data type (label)
(s1) Single-precision real number data or the start device where
the single-precision real number data is stored
0, 2
-126
|(s1)|<2
128
Single-precision real
number
ANYREAL_32
(s2) Decimal part digit data 0 to 7 16-bit signed binary ANY16
(d) Start device for storing the BCD format data  16-bit signed binary ANY16_ARRAY
(Number of elements: 5)
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s1)   
(s2)   
(d)   
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s1) (s2) (d)
EN ENO
ds1
s2
