Appendix 2 Number of Basic Steps and Availability of Subset Processing

2031

Appendix 2 Number of Basic Steps and Availability of

Subset Processing

The number of basic steps and the availability of subset processing are shown below.

Instruction name Number of basic steps Subset availability

LD 1 

LDI 1 

AND 1 

ANI 1 

OR 1 

ORI 1 

LDP 2 

LDF 2 

ANDP 2 

ANDF 2 

ORP 2 

ORF 2 

LDPI 2 

LDFI 2 

ANDPI 2 

ANDFI 2 

ORPI 2 

ORFI 2 

ANB 1 

ORB 1 

MPS 1 

MRD 1 

MPP 1 

INV 1 

MEP 1 

MEF 1 

EGP 1 

EGF 1 

OUT 1 

OUT T/ST 4 

OUT LT/LST 2 

OUT C 4 

OUT LC 4 

OUT F 2 

TH T/ST 4 

SET 1 

RST 1 

SET F 3 

RST F 3 

PLS 2 

PLF 2 

FF 2 

DELTA 2 

DELTAP 3 

SFT 2 

SFTP 3 

MC 2 

MCR 1 
