Mitsubishi Electric MELSEC iQ-R Series - Calculating the Square Root of BCD 8-Digit Data

7 APPLICATION INSTRUCTIONS
7.9 Real Number Instructions
829
7
Calculating the square root of BCD 8-digit data
BDSQRT(P)
These instructions calculate the square root of the value specified by a BCD 8-digit data.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
ENO:=BDSQRT(EN,s,d);
ENO:=BDSQRTP(EN,s,d);
FBD/LD
Instruction Execution condition
BDSQRT
BDSQRTP
Operand Description Range Data type Data type (label)
(s) Data used for square root operation, or the start device
containing the data
0 to 99999999 BCD 8-digit ANY32
(d) Start device for storing the operation result  BCD 4-digit ANY16_ARRAY
(Number of elements: 2)
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)         
(d)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d)
EN ENO
ds
