7 APPLICATION INSTRUCTIONS
7.8 String Processing Instructions
689
7
Extracting string data from the right
RIGHT(P)
These instructions extract (n) characters of data from the right of string data.
*1 The RIGHT instruction does not support the ST and FBD/LD. Use the standard function, RIGHT.
Page 1946 LEFT(_E), RIGHT(_E)
■Execution condition
Setting data
■Descriptions, ranges, and data types
■Applicable devices
Ladder ST
*1
ENO:=RIGHTP(EN,s,n,d);
FBD/LD
*1
Instruction Execution condition
RIGHT
RIGHTP
Operand Description Range Data type Data type (label)
(s) Character string or the start device containing the character
string
 String ANYSTRING_SINGLE
(d) Start device for storing (n) characters of character string
extracted from the right of the data in the device specified by (s)
 String ANYSTRING_SINGLE
(n) Number of characters to be extracted 1 to 16383 16-bit unsigned binary ANY16
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)   
(d)         
(n)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d) (n)
EN ENO
sd
n
