7.8 String Processing Instructions
• These instructions extract (n) characters of data from the right of the character string data (the end of the character string)
stored in the device number specified by (s) and later, and store the extracted data in the device number specified by (d)
and later.
When (n)=5
• The NULL code (00H) indicating the end of a character string is automatically added to the end of the character string data.
• When the number of characters in the device specified by (n) is 0, NULL code (00H) is stored in the device specified by (n).
(1) ASCII code (5th character)
Error code
(SD0)
Description
2820H There is no NULL code (00H) in each setting area in the device/label memory in the device specified by (s) and later.
3405H An out-of-range value is set to (s).
• The number of characters of the character string in the device specified by (s) exceeds 16383.
• The number of characters of the character string in the device specified by (s) is 0.
The number of characters in the device specify by (n) exceeds that in the device specified by (s).
00H
00H
b15 b0 b7b8
b15 b0 b7b8
(s)
(s)+1
(d)
(d)+1
ASCII code (1st character)ASCII code (2nd character)
ASCII code (3rd character)ASCII code (4th character)
ASCII code ((last-n+1)th character)ASCII code ((last-n+2)th character)
ASCII code ((last-n+3)th character)ASCII code ((last-n+4)th character)
ASCII code ((last-2)th character)ASCII code ((last-1)th character)
ASCII code (last character)
ASCII code ((last-n+1)th character)ASCII code ((last-n+2)th character)
ASCII code ((last-n+3)th character)ASCII code ((last-n+4)th character)
ASCII code ((last-2)th character)ASCII code ((last-1)th character)
ASCII code (last character)
41H (A)42H (B)
43H (C)44H (D)
31H (1)32H (2)
33H (3)34H (4)
45H (E)46H (F)
31H (1)32H (2)
33H (3)34H (4)
35H (5)00H
35H (5)00H
"ABCDEF12345"
"12345"
b15 b0 b7b8
b15 b0 b7b8
(s)
(s)+1
(s)+2
(s)+3
(s)+4
(s)+5
(d)
(d)+1
(d)+2
