6 BASIC INSTRUCTIONS
6.6 Data Conversion Instructions
441
6
Converting decimal ASCII data to 32-bit binary data
DDABIN(P)(_U)
These instructions convert decimal ASCII data to 32-bit binary data.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
ENO:=DDABIN(EN,s,d);
ENO:=DDABINP(EN,s,d);
ENO:=DDABIN_U(EN,s,d);
ENO:=DDABINP_U(EN,s,d);
FBD/LD
Instruction Execution condition
DDABIN
DDABIN_U
DDABINP
DDABINP_U
Operand Description Range Data type Data type (label)
(s) ASCII data to be converted to binary data or
the start device where the ASCII data is stored
 String ANYSTRING_SINGLE
(d) DDABIN(P) Start device for storing the conversion result  32-bit signed binary ANY32_S
DDABIN(P)_U 32-bit unsigned binary ANY32_U
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)   
(d)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d)
EN ENO
ds
