Transferring 1-bit data
MOVB(P)
These instructions transfer the specified 1-bit data.
■Execution condition
Setting data
■Description, range, data type
• In safety programs executed by the Safety CPU, only safety devices and safety labels of data types described in the table
can be used.
■Applicable devices
• In safety programs executed by the Safety CPU, only the following safety devices and constants can be used.
Ladder ST
ENO:=MOVB(EN,s,d);
ENO:=MOVBP(EN,s,d);
FBD/LD
Instruction Execution condition
MOVB
MOVBP
Operand Description Range Data type Data type (label)
(s) Number of the device where the transfer target data is
stored
 Bit ANY_BOOL
(d) Transfer destination device number  Bit ANY_BOOL
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)         
(d)         
Operand Bit Word Constant
SA\X, SA\Y, SA\M, SA\SM, SA\B SA\T, SA\ST, SA\C, SA\D, SA\W, SA\SD K, H
(s) 
(d) 
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d)
EN ENO
ds
