7 APPLICATION INSTRUCTIONS
7.4 Structure Creation Instructions
557
7
Forcibly terminating the FOR to NEXT instruction loop
BREAK(P)
These instructions forcibly terminate the loop processing between the FOR and NEXT instructions, and pass the control to the
specified pointer.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
Not supported
FBD/LD
Instruction Execution condition
BREAK
BREAKP
Operand Description Range Data type Data type (label)
(d) Number of the device for storing the remaining number of
loops
 16-bit signed binary ANY16
(P) Branch destination pointer number at the time of forced
termination of loop processing
 Device name POINTER
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
(P)
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(d)         
(P)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(d) (P)
EN ENO
Pd
