Appendix 1 Instruction Processing Time
2001
A
APPENDICES
Appendix 1 Instruction Processing Time
The following table lists the processing time of each instruction.
The processing time varies slightly depending on the contents of the source and destination. Assume that the values in the
table are reference processing time.
When using the file register (R/ZR), module access device (U\G), or link direct device (J\), add extra
time described in the section below to each instruction processing time.
Page 2030 Time added to instruction processing time
Instruction name Condition Processing time (s)
Minimum Maximum
LD When executed 0.00098
LDI When executed 0.00098
AND When executed 0.00098
ANI When executed 0.00098
OR When executed 0.00098
ORI When executed 0.00098
LDP When executed 0.00294
LDF When executed 0.00294
ANDP When executed 0.00294
ANDF When executed 0.00294
ORP When executed 0.00294
ORF When executed 0.00294
LDPI When executed 0.00294
LDFI When executed 0.00294
ANDPI When executed 0.00294
ANDFI When executed 0.00294
ORPI When executed 0.00294
ORFI When executed 0.00294
ANB 0.00098
ORB 0.00098
MPS 0.00098
MRD 0.00098
MPP 0.00098
INV When not executed/When executed 0.00098
MEP When not executed/When executed 0.00098
MEF When not executed/When executed 0.00098
EGP When not executed/When executed 0.00196
EGF When not executed/When executed 0.00196
OUT When not executed/When executed 0.00196
OUT (F) When not executed 0.00696
When executed 50.900 81.600
OUT (T/ST/C) When not executed 0.01196
When executed: when counting/after timeout 0.01196
OUT (LT/LST) When not executed 0.00996
When executed: when counting/after timeout 0.00996
OUT (LC) When not executed 0.01196
When executed: when counting/after timeout 0.01196
