Mitsubishi Electric MELSEC iQ-R Series - Page 2004

2002
APPX
Appendix 1 Instruction Processing Time
SET When not executed 0.00196
When executed: when the value is changed/when the value is not changed 0.00196
SET (F) When not executed 0.00696
When executed 50.300 81.700
RST When not executed 0.00196
When executed: when the value is changed/when the value is not changed 0.00196
RST (F) When not executed 0.00196
When executed 15.900 29.300
RST (T/ST/C) When not executed 0.00996
When executed 0.00996
RST (LT/LST) When not executed 0.00596
When executed 0.00596
RST (LC) When not executed 0.00996
When executed 0.00996
PLS  0.00196
PLF  0.00196
FF When not executed/When executed 0.00196
DELTA When not executed 0.00392
When executed 1.700 6.300
SFT When not executed 0.00392
When executed 0.900 3.300
MC  0.00196
MCR  0.00196
FEND  Refer to the following.
MELSEC iQ-R CPU Module User's
Manual (Application)
END 
STOP  
NOP  0.00098
LD= Continuity/Non-continuity 0.00588
LD<> Continuity/Non-continuity 0.00588
LD> Continuity/Non-continuity 0.00588
LD<= Continuity/Non-continuity 0.00588
LD< Continuity/Non-continuity 0.00588
LD>= Continuity/Non-continuity 0.00588
AND= When not executed 0.00392
When executed: continuity/non-continuity 0.00588
AND<> When not executed 0.00392
When executed: continuity/non-continuity 0.00588
AND> When not executed 0.00392
When executed: continuity/non-continuity 0.00588
AND<= When not executed 0.00392
When executed: continuity/non-continuity 0.00588
AND< When not executed 0.00392
When executed: continuity/non-continuity 0.00588
AND>= When not executed 0.00392
When executed: continuity/non-continuity 0.00588
OR= When not executed 0.00392
When executed: continuity/non-continuity 0.00588
OR<> When not executed 0.00392
When executed: continuity/non-continuity 0.00588
OR> When not executed 0.00392
When executed: continuity/non-continuity 0.00588
Instruction name Condition Processing time (s)
Minimum Maximum
