6 BASIC INSTRUCTIONS
6.2 Arithmetic Operation Instructions
Multiplying BCD 4-digit data
B*(P)
These instructions multiply the two sets of BCD 4-digit data specified.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
Not supported
FBD/LD
( is to be replaced by either of the following: BMULTI, BMULTIP.)
Instruction Execution condition
B*
B*P
Operand Description Range Data type Data type (label)
(s1) Multiplicand data or the device where multiplicand data is
stored
0 to 9999 BCD 4-digit ANY16
(s2) Multiplier data or the device where multiplier data is stored 0 to 9999 BCD 4-digit ANY16
(d) Start device for storing the operation result  BCD 8-digit ANY32
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s1)         
(s2)         
(d)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s1) (s2) (d)
EN ENO
ds1
s2
