158
4 STANDARD FUNCTIONS/FUNCTION BLOCKS
4.2 Standard Function Flocks
■Counter function block
Timer function blocks
■Pulse timer
■On delay timer
■Off delay timer
■Timer function block
Function block symbol Processing details Reference
COUNTER_FB_M Starts counting up when the execution condition is satisfied. Page 1987
COUNTER_FB_M
Function block symbol Processing details Reference
TP Keeps the signal on for the specified period of time. Page 1989 TP(_E)
TP_E
Function block symbol Processing details Reference
TON Turns on a signal after the specified period of time. Page 1992 TON(_E)
TON_E
Function block symbol Processing details Reference
TOF Turns off a signal after the specified period of time. Page 1995 TOF(_E)
TOF_E
Function block symbol Processing details Reference
TIMER_10_FB_M Starts counting a timer when the execution condition is satisfied, and continues counting until the
timer reaches the set value.
Page 1997
TIMER__M
TIMER_100_FB_M
TIMER_HIGH_FB_M
TIMER_LOW_FB_M
TIMER_CONT_FB_M
TIMER_CONTHFB_M
To Next Page
