6 BASIC INSTRUCTIONS
6.6 Data Conversion Instructions
397
6
Processing details
• These instructions convert the double-precision real number in the device specified by (s) to 16-bit unsigned binary data,
and store the converted data in the device specified by (d).
• After conversion, the first digit after the decimal point of the double-precision real number is rounded off.
• When an input value is set using the engineering tool, a rounding error may occur. For the precautions on setting an input
value using the engineering tool, refer to the following.
Page 49 Precautions
The following program example converts, when M0 turns on, the double-precision real number stored in D0 to D3 to 16-bit
unsigned binary data, and stores the converted data in D100.
Operation error
Error code
(SD0)
Description
3401H The double-precision real number in the device specified by (s) is out of the range, 0 to 65535.
3402H An unusual number is set to (s).
• The double-precision real number set to (s) is not within the following range:
0, 2
-1022
|(s)|<2
1024
• The value set to a device or label is -0, a subnormal number, NaN (not a number), or .
b63 b49
(5432.1)
3819H40B5H
D3, D2, D1, D0
b48 b32
(s)
b31 b16
999AH9999H
b15 b0
(d)
(5432)
1538H
b15 b0
D100
    
SM402
(s)
(d)
M0
EDMOVP
E5432.1 D0
DBL2UINT
D0 D100
