Mitsubishi Electric MELSEC iQ-R Series

To Next Page

To Previous Page

6 BASIC INSTRUCTIONS

6.6 Data Conversion Instructions

433

Processing details

• These instructions convert the 32-bit binary Gray code data in the device specified by (s) to 32-bit binary data, and store the

converted data in the device specified by (d).

Operation error

(s)+1: Upper 16 bits

(s): Lower 16 bits

Error code

(SD0)

Description

3401H When the DGBIN(P) instruction is used, the value in the device specified by (s) is out of the range, 0 to 2147483647.

(d) BIN

305419896

001 0 0 1 0 0 0 1 1 0 1 0 0 0 1 0 1 0 1 1 0 0 1 1 1 1 0 00

b31 b16 b0b15

305419896

001 1 0 1 1 0 0 1 0 1 1 1 0 0 1 1 1 1 1 0 1 0 1 0 0 0 1 00

(d)+1

b31 b16 b0b15

(d)



(s)

(s)+1 (s)
