6 BASIC INSTRUCTIONS
6.6 Data Conversion Instructions
437
6
Processing details
• These instructions convert the (n) points of BCD data (0 to 9999) starting from the device specified by (s) to 16-bit binary
data, and store the converted data in the device specified by (d) and later.
Operation error
Error code
(SD0)
Description
2821H The device ranges specified by (s) and (d) are overlapping.
3401H The (n) points of data starting from the device specified by (s) is out of the range, 0 to 9999.
(s)
(s)+1
(s)+2
(s)+(n)-2
(s)+(n)-1
(d)
(d)+1
(d)+2
(d)+(n)-2
(d)+(n)-1
BCD 5555
BCD 4321
BCD 1545
BCD 5678
BCD 1234
BIN 1234
BIN 5678
BIN 1545
BIN 4321
BIN 5555

   
(n)
(n)
0 001010110110011
0 001000011100001
0 000011000001001
0 001011000101110
0 000010011010010
0 101010101010101
0 100001100100001
0001010101000101
0 101011001111000
0 001001000110100
8000 4000 2000 1000 800 400 200 100 80 40 20 10 8 4 2 1
8192 4096 2048 1024 512 256 128 64 32 16 8 4 2 1
BIN
