VRRP
159
Managed Switches
A screen similar to the following displays.
b. Under Global Configuration, next to the Admin Mode, select Enable radio button.
c. Enter the following information in the VRRP Configuration:
• In the VRID (1 to 255) field, enter 20.
• In the Interface field, select 1/0/2.
• In the Primary IP Address field, enter 192.150.2.1.
• In the Mode field, select Active.
d. Click Apply to save the settings.
VRRP on a Backup Router
The example is shown as CLI commands and as a web interface procedure.
CLI: Configure VRRP on a Backup Router
1. Enable routing for the switch. IP forwarding will then be enabled by default.
2. Configure the IP addresses and subnet masks for the port that will participate in the protocol.
3. Enable VRRP for the switch.
(Netgear Switch) #config
(Netgear Switch) (Config)#ip routing
(Netgear Switch) (Config)#interface 1/0/4
(Netgear Switch) (Interface 1/0/4)#routing
(Netgear Switch) (Interface 1/0/4)#ip address 192.150.4.1 255.255.0.0
(Netgear Switch) (Interface 1/0/4)#exit
(Netgear Switch) (Config)#ip vrrp
