Switch Stacks
440
Managed Switches
Stack Switches Using a 10G Copper Port
This example shows how to stack two switches at close range.
Figure 48. Connect switches through their 10G copper ports
 To set up a stack between two switches:
1. Using a Cat6e Ethernet cable, connect a 10G copper port on one switch with a 10G copper
port on the other switch.
2. Configure the Switch A and Switch B as described in one of the following sections:
• CLI: Configure the 10G Copper Ports as Stack Ports on page 441
• Web Interface: Copy Master Firmware to a Stack Member on page 439
2/0/28
1/0/28
Switch A
Switch B
