DHCP L2 Relay and L3 Relay

610

Managed Switches

Figure 60. DHCP L3 relay

Configure the DHCP L3 Server in a Windows Server Operating

System

1. In the Windows Server operating system, open the Server Manager.

2. In the menu tree on the left, click Roles.

DHCP server

Switch functioning as

1/0/3

1/0/4

1/0/15

1/0/16

a DHCP L3 relay

Default Chapter3
