OSPF
123
Managed Switches
c. Click Apply to save the settings.
5. Configure area 0.0.0.1 as a stub area.
a. Select Routing > OSPF > Advanced > Stub Area Configuration.
A screen similar to the following displays.
b. In the Area ID field, enter 0.0.0.1.
c. Click Add to save the settings.
NSSA Areas
Figure 15. NSSA area
The example is shown as CLI commands and as a web interface procedure.
CLI: Configure Area 1 as an NSSA Area
1. Enable routing on the switch.
(Netgear Switch) #config
(Netgear Switch) (Config)#router ospf
(Netgear Switch) (Config)#ip routing
Port 2/0/11
Port 2/0/19
Port 1/0/15
Layer 3
Switch
Area 0 Area 1
Layer 3
switch
To Next Page
