STP
504
Managed Switches
b. Enter the following information:
• For Spanning Tree Admin Mode, select the Enable radio button.
• For Force Protocol Version, select the IEEE 802.1d radio button.
c. Click Apply.
2. Configure the CST port.
a. Select Switching > STP > CST Port Configuration.
A screen similar to the following displays.
b. Under CST Port Configuration, scroll down and select the Interface 1/0/3 check box.
Now 1/0/3 appears in the Interface field at the top.
c. In the Port Mode field, select Enable.
d. Click Apply.
Configure Rapid STP (802.1w)
The example is shown as CLI commands and as a web interface procedure.
CLI: Configure Rapid STP (802.1w)
(Netgear switch) (Config)# spanning-tree
(Netgear switch) (Config)# spanning-tree mode rstp
(Netgear switch) (Interface 1/0/3)# spanning-tree port mode
