ACLs
195
Managed Switches
e. Click Apply to save the settings.
13. Apply ACL 103 to port 24 and port 48:
a. Select Security > ACL > Advanced > IP Binding Configuration.
A screen similar to the following displays.
b. Under Binding Configuration, make the following selection and enter the following
information:
• In the ACL ID field, select 103.
• In the Sequence Number field, enter 2.
c. Click Unit 1. The ports display.
Configure the following ports:
• Click the gray box under port 24. A check mark displays in the box.
• Click the gray box under port 48. A check mark displays in the box.
d. Click Apply to save the settings.
Set up a MAC ACL with Two Rules
The example is shown as CLI commands and as a web interface procedure.
CLI: Set up a MAC ACL with Two Rules
1. Create a new MAC ACL acl_bpdu.
2. Deny all the traffic that has destination MAC 01:80:c2:xx:xx:xx.
(Netgear Switch) #
(Netgear Switch) #config
(Netgear Switch) (Config)#mac access-list extended acl_bpdu
(Netgear Switch) (Config-mac-access-list)#deny any 01:80:c2:00:00:00
00:00:00:ff:ff:ff
