DiffServ
257
Managed Switches
Example 1: Enable Protocol-Based Auto VoIP
This example is provided as CLI commands and as a web interface procedure.
CLI: Protocol-Based Auto VoIP
This script in this section shows how to set up Auto VoIP per port.
1. Enable protocol-based Auto VoIP on a specific port of the switch.
2. Display the Auto VoIP information.
Web Interface: Configure Protocol-Based Auto VoIP
1. Enable protocol-based Auto VoIP on a specific port of the switch:
a. Select Switching > Auto-VoIP > Protocol-based > Port Settings.
A screen similar to the following displays.
b. Scroll down and select the interface 2/0/1 check box.
The Interface field in the table heading displays 2/0/1.
c. From the Auto VoIP Mode mode, select Enable.
d. Click Apply.
(Netgear Switch)(Configure)#interface 2/0/1
(Netgear Switch)(Interface 2/0/1)#auto-voip protocol-based
(Netgear Switch) #show auto-voip protocol-based interface 2/0/1
VoIP VLAN Id................................... 2
Prioritization Type............................ traffic-class
Class Value.................................... 6
Interface Auto VoIP Mode Operational Status
--------- -------------- -----------------
2/0/1 Enabled Up
