NETGEAR M4200 User Manual

DVLANs and Private VLANs
498
Managed Switches
5. Add 1/0/16 and 1/0/7 to the private group 1.
6. Add 1/0/16 and 1/0/7 to the private group 2.
Web Interface: Create a Private VLAN Group
1. Create VLAN 200.
a. Select Switching > VLAN > Basic > VLAN Configuration.
A screen similar to the following displays.
b. Enter the following information:
• In the VLAN ID field, enter 200.
• In the VLAN Name field, enter VLAN200.
• In the VLAN Type field, select Static.
c. Click Add.
2. Add ports 1/0/6, 1/0/7, 1/0/16, and 1/0/17 to VLAN 200.
a. Select Switching > VLAN > Advanced > VLAN Membership.
(Netgear Switch) (Config)#interface range 1/0/16-1/0/17
(Netgear Switch) (conf-if-range-1/0/16-1/0/17)#switchport private-group 2
(Netgear Switch) (conf-if-range-1/0/16-1/0/17)#exit
