DHCPv6 Server

488

Managed Switches

CLI: Set Up a Configuration With a DHCPv6 Server and

DHCPv6 Relay

Figure 51. Configuration with a DHCPv6 server and DHCPv6 relay

This is a two-step process:

• Configure the DHCPv6 Server

• Configure the DHCPv6 Relay

Configure the DHCPv6 Server

1. Enable IPv6 routing.

2. Create a DHCPv6 pool and enable DHCP service.

(Netgear Switch) (Config)#ipv6 dhcp pool ipv6_server

(Netgear Switch) (Config)#ip routing

(Netgear Switch) (Config)#service dhcpv6

(Netgear Switch) (Config)#ipv6 dhcp pool pool1

(Netgear Switch) (Config-dhcp6s-pool)#domain-name netgear.com

(Netgear Switch) (Config-dhcp6s-pool)#address prefix 2001:2::/64

(Netgear Switch) (Config-dhcp6s-pool)#exit

DHCPv6

Server

DHCPv6

Relay

DHCPv6

Client

1/0/20

1/0/19

Default Chapter3
